TA'RIFI
ILOVA
These cables are designed for installations in elevators, dumbwaiters, personnel, and material hoists.
Xususiyatlari
Past kuchlanish
Olovni ushlab turuvchi
QURILISh
-
MARKAZIY PO'LAT TAYYORLASH KABELI:Flexible, performance rated, galvanized steel wire rope support strand, manufactured to Military Specification MIL-W-83420. The steel core has 60C flame-retardant polyvinyl chloride insulation and a reinforcing tightly woven braid of cotton or rayon.
-
INSULATED CONDUCTORS:Soft-annealed, bunched stranded bare copper per ASTM Standards B3 and B174. The conductors are insulated with flame retardant 60°C polyvinyl chloride and are rated at 300 volts in accordance with the requirements of UL 62, CSA C22 .2 No. 49 and the appropriate articles of the NEC and Canadian Electrical codes. Each conductor is color and number-coded for easy identification.
-
SHIELDED PAIRS (OPTIONAL):Two insulated 20 AWG soft-drawn bare copper conductors, PVC insulated, twisted with a bare drain wire. The laminated polyester and aluminum foil tape creates 100% shield coverage. The assembly has an overall colored PVC jacket and rated 300V.
-
COAXIAL CABLE (OPTIONAL):RG-6, 75 ohm va 300V kuchlanishli koaksial kabel.
-
TO'LDIRUVCHILAR:Kabelga dumaloq kesim berish, burish barqarorligini oshirish va egilish paytida konstruksiyani yumshatish uchun tolali-qatlamli jut plomba moddalari.
-
BO'YASH:A tightly woven braid of cotton, rayon, or equivalent applied over the core to help maintain core shape, torsion balance and add mechanical strength.
-
KURTKA:Polivinilxloridning umumiy qoplamasi UL 1581 olov sinovi talablariga javob beradigan silliq, egiluvchan, aşınmaya bardoshli qoplamani ta'minlaydi va CSA FT-1 olovga chidamlilik darajasiga ega.
PARAMETRE
- 1 stol
- 2 stol
- 3 stol
| O'ZAKLAR SONI X KESIMI | NOMINAL UMUMIY DIAMETR | KABEL OG'IRLIGI | PO'LAT YADROSI DIAMETRI |
| NX AWG | MM | KG/KM | MM |
| 4x14 | 14.5 | 247 | 2.4 |
| 8x14 | 17.8 | 436 | 3.2 |
| 15x14 | 23.6 | 725 | 3.2 |
| 6x18 | 12.4 | 185 | 2.4 |
| 10x18 | 13.7 | 265 | 2.4 |
| 20x18 | 17.8 | 426 | 2.4 |
| 30x18 | 20.8 | 620 | 3.2 |
| 40x18 | 23.4 | 795 | 4.0 |
| 45x18 | 23.6 | 808 | 3.2 |
| 75x18 | 30.2 | 1348 | 4.0 |
